iFlight Mach R5 FPV Racing Frame Kit – DJI/Analog

In response to our customer needs, this is our answer for all the racers in out there: The iFlight Mach R5!
Quick-swap arm assembly for easy repair on your flying spot or race day.
Enhanced canopy design with low wind resistance for maximum speed and efficiency.

FEATURES:

– Super durable design, 6mm arms and 7075 CNC middle plate

– 30.5*30.5/25.5*25.5mm/20*20mm mount holes for all flight controllers

– Compact & easy repairing design

Specifications:

-Wheelbase: 215mm

-Main body dimension: 152*152mm

-Arm thickness: 6mm

-Bottom plate thickness: 3mm

-Top plate thickness: 2.5mm

-Middle Plate thickness: 2.5mm CNC 7075 aluminum alloy

-TPU Camera plate

-FC: 30.5*30.5/25.5*25.5mm/20*20mm

-FPV Cam: 14mm /19mm Micro / 20mm

Package included:

-1 x Mach R5 Frame

-2 x battery straps (20*250mm)

-1set x TPU parts

-2x 2mm Anti-slip Battery Pads
