Karearea NEW TOA LITE 2208 Series – 1850Kv
Check out all of our Karearea products! Also, take a look at all of our 1850kv motors!
Specifications
- Configuration / 12N14P
- 1 Piece Unibody outer motor bell
- Stator / Kawasaki 0.15 (0.1-0.12 Air gap)
- Weight / 34.2 grams (without cable)
- Wire Length / 15cm
- Wire Gauge / 20 AWG
- 0.1mm -0.12mm Air gap
​
- Recommended Props / 5 or 6 inch
- LiPo Compatibility / 2-8S
- Prop Mount Diameter / 5mm
- Shaft / Semi-hollow, Titanium TC4 GRADEÂ –Â CW threads
- Magnets / N52SHÂ Arc magnet
- Set Screw / 2mm
- NSK bearing (4x9x4)
- Single winding
​
- KV (rpm/Volt) 1850, 2150, 2450, 2650 : 4 Different KV selection
- Idle current @10v(A) 0.9A 1850KV / No of Cells(Lipo) 2-8S
- Idle current @10v(A)Â 1.2A 2250KV /Â No of Cells(Lipo) 2-6S
- Idle current @10v(A)Â 1.4A 2450KV /Â No of Cells(Lipo) 2-6S
- Idle current @10v(A)Â 1.6A 2650KV /Â No of Cells(Lipo) 2-5S
