Matek FCHUB-12S PDB X-Class
Power your giant-scale FPV drone with the Matek FCHUB-12S, a Power Distribution Board (PDB) engineered for the extreme demands of X-Class racing and other large multirotors. This PDB is designed to be the robust and reliable heart of your power system, capable of handling up to 12S LiPo voltage and delivering massive current to your ESCs. It’s the professional-grade drone part you need for a high-power FPV drone build.
Extreme Power for X-Class Drones
The FCHUB-12S is built to handle incredible power. It supports a wide input voltage range from 3S all the way up to 12S (8-60V) and can distribute 70A of continuous current (110A burst) to four separate ESCs. The onboard current sensor is rated for up to 440A, providing accurate power consumption data for your high-performance FPV drone.
Robust & Versatile BEC Outputs
This PDB features multiple, high-power BECs (Battery Eliminator Circuits) to provide clean, stable voltage for all your components:
- 5V @ 5A BEC: Provides plenty of power for your flight controller, receiver, GPS, and other 5V peripherals.
- 12V @ 4A BEC: Perfect for powering FPV cameras and high-power video transmitters.
- Switchable 12V Output: A dedicated pad can be controlled via your flight controller (PINIO), allowing you to turn your VTX or LEDs on and off remotely.
Designed for Clean & Reliable Builds
The FCHUB-12S features a convenient 8-pin JST-SH connector, designed to pair perfectly with Matek flight controllers like the F765-Wing or H743 series. This allows for a single, clean cable connection that carries all four ESC signals, telemetry, and power, dramatically simplifying the wiring of your FPV drone kit.
Specifications
- Brand: Matek
- Model: FCHUB-12S
- Input Voltage: 8V – 60V (3-12S LiPo)
- PDB Rating: 4x 70A Continuous, 4x 110A Burst
- Current Sensor: 440A
- BEC 1: 5V @ 5A
- BEC 2: 12V @ 4A
- BEC 3: Switchable 12V @ 2A
- Mounting: 30.5mm x 30.5mm (M3)
- Dimensions: 55 x 50 x 6 mm
- Weight: 21g
What’s in the Box?
- 1x Matek FCHUB-12S V2 PDB
- 1x Rubycon ZLH 35V/470uF Low ESR Capacitor
- 1x SH1.0_8pin Cable (5cm)
- 2x SH1.0_8pin Connectors
