CLRACING 4IN1 45A 32BIT ESC V2 – 30X30MM
Check out all of our CL Racing products, as well as all of our ESCs
Super fast and reliable 32-bit ESC by CL Racing.
It can also be Replacement ESC for the CLRACING F7/4in1 stack combo.
Specifications
- LIPO: 2-6S LIPO
- Weight:13.5g
- Firmware: Blheli_32
- Size : 43.5mm x 46.5mm
- Mounting: 30.5mm x 30.5mm / ID 4mm
- Con.Current:45A, Peak 55A @10s
- Support: Dshot300-1200/MultiShot/OneShot/ProShot/PMW
- Connection: PNP with CLRACING F7 FC, with JST1.0 8-pin connector or soldering pads
- Current scale: 250
Accessories
- 10 x M3*5mm nylon thread through spacers
- 5 x M3*25mm nylon screws
- 5 x M3 nylon nuts
- 5 x Yellow Grommets
- 2 x 14 AWG 80mm Silicone wires
- 1 x connection cable
- 1 x Amass XT60
- 1 x Rubycon 1000uf 35v ZLH capacitor
