M6AC Smart AC LiPo Battery Charger

Professional Charging Solution for RC Enthusiasts

The ToolkitRC M6AC Smart AC/DC LiPo Battery Charger is a versatile and portable charging station designed for FPV drone pilots, RC car enthusiasts, and aviation hobbyists. With 300W charging power, 6S battery support, and a crisp 2.0″ IPS LCD display, this charger delivers reliable performance for LiPo, LiHV, LiFe, Li-ion, NiMH, and Pb batteries. Its built-in PWM/PPM/SBUS measurement and generation capabilities make it an indispensable tool for RC system diagnostics and calibration.

Key Features & Technical Specifications

High-Performance Charging

• 300W Maximum Charging Power (0.1-15A adjustable current)

• Dual Input Options:

  • AC 100-240V (120W max)

  • DC 7-35V (30A max)

• Wide Battery Compatibility:

  • LiPo/LiHV/LiFe/Li-ion/LTO (1-6S)

  • NiMH (1-16S)

  • Pb (1-10S)

Precision Battery Management

• High-Accuracy Balancing: 1000mA balance current with <0.005V cell accuracy

• Advanced Discharge Modes:

  • 300W Regenerative Discharge (energy recycling)

  • 15W Internal Discharge (0.1-3A)

• Internal Resistance Measurement: 0.1mΩ-99mΩ range for battery health monitoring

RC System Diagnostics

• Signal Measurement:

  • PWM (880-2200μs @ 20-400Hz)

  • PPM (8 channels @ 20-50Hz)

  • SBUS (16 channels @ 20-100Hz)

• Signal Generation:

  • PWM output (500-2500μs @ 20-1000Hz)

  • PPM output (8 channels @ 50Hz)

  • SBUS output (16 channels @ 74Hz)

Compact & User-Friendly Design

• 2.0″ IPS LCD Display (320×240 resolution) for clear parameter monitoring

• Lightweight & Portable: Only 350g (108×106×60mm)

• USB-A Power Output: 5V/1A (10W) for accessory charging

• CC+CV Mode: 0.5-15A @ 1-28V output range

Who Should Use This Charger?

• FPV Drone Pilots – Fast-charge 6S LiPo batteries with precision balancing

• RC Car & Airplane Enthusiasts – Supports multiple battery chemistries

• RC Technicians – Built-in signal measurement for system troubleshooting

• Field Users – Compact size ideal for portable charging setups

Why Choose the M6AC?

✔ All-in-One Functionality – Combines charging, discharging, and RC signal testing
✔ Precision Control – High-accuracy balancing for battery longevity
✔ Portable Powerhouse – 300W performance in a compact 350g package
✔ ToolkitRC Reliability – Trusted brand in professional charging solutions

Package Contents

• M6AC Charger × 1

• AC Input Cable × 1

• USB Cable × 1

• Quick Manual × 1

• Screen Protector × 1
