ToolkitRC M8P Battery Charger
The ToolkitRC M8P Charger stands out as a compact and efficient charging option, ideal for FPV drones and cinematographic uses. It features a bright touchscreen for easy manipulation of charging settings and is compatible with various XT60 battery types, highlighting its versatility. The charger’s portable nature makes it perfect for on-site charging, proving indispensable for both drone hobbyists and professional cinematographers.
Key Features
- 600W DC Charging Capacity
- Compatible with 1-8S Batteries
- Designed with an XT60 Connector
Technical Specifications
- Dimensions: 100x71x34mm
- Weight: 200g
Charging Features
- Input Voltage: 7-35V, Maximum 25A
- Supported Battery Types: LiPo, LiHV, LiFe, Lion, LTO (1-8S), NiMh (1-20S), Pb (1-10S)
- Charging Power: Adjustable from 0.1 to 20A, up to 600W
- Discharge Power: 0.1-20A at 600W (Recycle External), 0.1-3A at 20W (Normal mode)
- Balance Current: 1000mA at 4.2V
- USB Output: 5.0V at 2.1A (upgraded)
Measurement Capabilities
- PWM: 880us-2200us at 20-400Hz
- PPM: 880us-2200us*8Ch at 20-50Hz
- SBUS: 880us-2200us*16ch at 20-100Hz
- Voltage Measurement: 1.0V-5.0V for 1-8S
- Internal Resistance: 1-99mR for 1-8S
- ESC: 1-20A at 1-35V, Maximum 600W
Output Features
- PWM: 500us-2500us at 20-1000Hz
- PPM: 880us-2200us*8ch at 50Hz
- SBUS: 880us-2200us*16ch at 74Hz
- Output Power: 1-20A at 1-35V, CC+CV Mode
- LCD Display: 2.4″ IPS RGB, 320×240 pixels
Additional Information
Package Contents
- 1 ToolkitRC M8P 1-8S 600W 20A DC Charger with XT60 Connector
