Happymodel Crux35 DJI HD BNF – ELRS V2
Check out all of our other HappyModel products! Also, take a look at our selection of Pre-Built Drones!
You can also get just the frame, or just the motors.
The HD version is equipped with CADDXFPV Nebula and Vista HD image transmission system. ExpressLRS is the most popular RC link system by now , it could performance very well with Crux35 and Crux35 HD.
Features:
Ultra-lightweight 3.5-inch BNF FPV Freestyle Drone
Integrated ExpressLRS SPI receiver
High efficiency EX1404 power system
Can be equipped with Naked Gopro or SMO4K
Support 3-4S battery 4S 750mah battery is recommended, maximum support 4S 1100mah
Specifications:
Model: Crux35 HD
Wheelbase: 150mm
Weight: 108g ( HD)
Size: 130mmx130mmx45mm(without propellers)
Receiver: UART ExpressLRS 2.4GHz (ELRS 2.4G RX)
Camera option: HD version Nebula+Vista
Flying time: 9min~15min 4s 750mah battery
| Caddx FPV Digital HD Camera Nebula Nano Kit
(Digital HD version) |
Weight(camera included]: 24g
Antenna: 2.3g Dimensions: Vista Kit 30×29×13mm Camera 14×14×21mm Operating Frequency: 5.725-5.850GHz Transmitter Power[EIRP]: FCC/SRRC/MIC:<30dBm CE:<14dBm Min.latencylend-to-end) 720p 60fps:32ms Max.Transmission Distance FcC/SRRC: 4km CE:0.7km lnput Power: 7.4-26.4V Power Output: 25mW/200mW/500mW/700mw Goggles : Work with DJl goggles Camera Sensor: 1/3”CMOS Lens: 2.1mm,f/2.1 Shutter: Rolling shutterFOV: 142°(D);122°(H);75°(V) LHCP antenna |
| Flight controller
(ELRS Version) |
MCU:STM32F411CEU6 (100MHZ, 512K FLASH) Sensor: ICM42688P or BMI270 (SPI Control) Mount pattern: 25.5×25.5 M2 Size:32*32*5mm Power supply: 2-4S Lipo battery Built-in 20A Blheli_s ESC each Built-in Betaflight OSD(SPI Control) Built-in UART ExpressLRS 2.4GHz receiver Built-in 5V 1.5A BEC Flight controller firmware target: CRAZYBEEF4DX |
