GEPRC Phantom HD Frame
The GEP-PTHD frame was attentively designed by the GEPRC team. It is very light and compact. The weighs about 19.7g. It can make flexible cross flight in a narrow environment.
Product specifications:
- Brand: GEPRC
- Item: GEP-PTHD
- Propeller: 2.5inch
- Motor to Motor: 125mm
- Hole size of motor: 9mm*9mm (suit with 1105/1103/1104/1204/motor)
- Hole size of FC: 25.5×25.5mm & 16x16mm
- Camera size：14mm*14mm
- Weight: 19.7g
PTHD Include：
- 1 x 2.5mm Bottom plate
- 1 x 1.5mm Top plate
- 2 x 1.0mm Side plate
- 3 x（M2*23）Aluminum posts black
- 6 x（M2*18）Plastic posts black
- 8 x（M2*2）Plastic nuts black
- 4 x（M2）Self tightening nuts black
- 4 x（M2*12）Cup head screws black
- 6 x（M2*6）YFS screws
- 1 x XT30 Power cord
- 1 x Fixing part of TBS Antenna Red
- 1 x Fixing part of XM Antenna Red
- 1 x Fixing part of Antenna Red
- 1 x Batteries pad
- 4 x Black Damping ring
- 4 x Red Damping ring
- 1 x Landing shock absorption pad
- 2 x Protect tube of receiver antenna
- 2 x Batteries strap black
