ETHIX Mr. Steele Stout Motor V5 Blue
Check out all of our Ethix Products, and all of our Motors!
Introducing the Mr. Steele V5 Stout 2307 (1950KV) 6S (5”-5.5” prop) FPV freestyle motor. The Stout motor is wound at 1950KV for extra power and speed.
The V5 features an increased stator size and a redesigned motor bell setup for more durability. This new iteration of my trusted power train formula follows a lightweight ethos with increased power and torque where it counts. Attaining a high power-to-weight ratio cannot overstate when building a high-performance aircraft.
Thank you for your support and take pride in knowing that you are the reason I am able to keep evolving in this amazing space we call the FPV community.
V5 MOTOR HIGHLIGHTS
- Increased stator size 2307
- Base redesign 16×16(only) mounting holes (new structural changes for more durability)
- Complete bell redesigned (durability and smoothness in mind)
- Thick single-strand copper winding
- Increased EFFICIENCY & POWER
- Complete Interchangeable motor pants redesign (thicker & more crash/low temperature resistant, better gap fitment, + more protection coverage for the “tall pants”)
- Better assembly tolerances
- Overall QC improvements
- 9mm steel bearings
- Eco-Friendly packaging
- Motor weight 33.8g (full-length cables) compared to Stout V1 at 31.5g
- Pants Weight – Low – 1g vs (0.8 v3) | Tall – 2g vs (1.8 v3)
All in all this motor is an absolute gem only increasing the weight by a tad over 1g from the previous model while achieving more power, efficiency, and most importantly durability.
Enjoy & Thank you for your continued support. -Steele
|Stator Size (Diameter)||23mm*7mm|
|Shaft Length (mm)||10.5mm|
|Shaft Diameter (mm)||4mm|
|Weight (With Wires)(g)||36.5g|
|Max Current (A)||45A|
|Max Burst Current (A)||60A|
|Internal Resistance (Rm)||60mΩ|
|Wire Spec (AWG)||20#-135mm|
|Base Mounting Pattern||16x16mm|
|Base Mounting Thread||M3 Thread|
|Motor Overall Dimensions||φ28.6mm*18.2mm|
