Diatone MAMBA TOKA 2808 1100KV FPV Racing Motor
Check out all of our Diatone Products!
Step up to a new class of power and performance with the Diatone Mamba TOKA 2808 1100KV motor. This powerhouse is engineered specifically for large-scale FPV drones, effortlessly spinning 7-inch propellers with massive torque and incredible efficiency. It’s the premier choice for pilots building long-range exploration rigs, professional cinematic platforms, and heavy-lift drones.
The heart of this motor is its massive 2808 stator, which, when paired with the 1100KV rating, is perfectly tuned for 6S LiPo systems. This combination delivers the immense torque required to control large 7-inch propellers with precision and authority. The result is incredibly stable flight, smooth throttle response for cinematic shots, and great efficiency for extending your flight times on long-range missions.
Built for durability and reliability under heavy loads, the Mamba TOKA 2808 features a robust 6mm internal steel shaft and large, high-quality bearings. The windings are made from 240℃ high-temperature enameled wire, ensuring the motor can handle sustained high-power output without breaking a sweat. With a peak power of over 860W, this motor provides the strength to carry larger batteries and professional cameras, making it the ideal foundation for any serious 7-inch project.
KEY FEATURES
- Massive 2808 Stator: Delivers huge torque for spinning 7-inch propellers with control and authority.
- Optimized 1100KV for 6S: Perfectly tuned for efficiency and smooth power delivery on 6S LiPo batteries.
- Ideal for 7-Inch Drones: The premier choice for long-range, cinematic, and heavy-lift FPV platforms.
- Robust Construction: Features a thick 6mm steel shaft and large, durable bearings for maximum reliability.
- High Power Output: Capable of producing over 860W of peak power for carrying heavy payloads.
SPECIFICATIONS
- KV: 1100
- Stator Size: 28mm x 8mm
- Color: Green
- Rated Voltage: 4-6S (16.8V – 25.2V)
- Bearing (Top): 10x6x4mm
- Bearing (Bottom): 13x6x5mm
- Shaft Diameter: 6.0mm
- Prop Mounting Shaft: 5mm
- Mounting Pattern: 16x16mm, M3
- Peak Current: 38.7A
- Maximum Power: 862.5W
- Weight: 63.5g
