Specifications:

Wheelbase ：198mm
Weight ：100g
Prop Size ：5 inch
FC Mounting:20×20mm（M2）
Motor Mounting:16mm(M3)
Camera Spacing:14mm
Max Stack Height: 20mm
Top Plate:2mm
Bottom Plate:2.5mm
Arm ：2.5mm
Rated Volitage（Recommendation）：4S~6S
carbon fiber:T300 3K
Recommended Motor Size: 22 Series motor

Carbon Fiber Parts

QTY 1 – Top Plate 2mm CF
QTY 1 – Mid Plate 2.5mm CF
QTY 1 – Bottom Plate 2.5mm CF
QTY 4 – Arm 3mm CF
QTY 4 – Motor Mount 2.5mm CF
QTY 2 – Dual Motor Mount 2.5mm CF
QTY 2 – Front/Rear Brace 3mm CF
QTY 2 – Side Brace 3mm CF

Hardware Kit

QTY 4 – M3x8mm Steel Bolts
QTY 4 – M3x20mm Steel Bolts
QTY 16 – M3x14mm Steel Socket Head bolts for motors
QTY 4 – M3x10 Black Knurled Standoffs
