RCinpower EX2306 plus 5inch Brushless Motor – 1800Kv/2500Kv

These motors are a new addition to the RCinPower motor family. Check out the other RCinpower motors too!

Get solid performance and reliability without breaking the bank with the RCinpower EX2306 Plus motor. From the renowned manufacturer RCinpower, this motor is designed to be a fantastic workhorse for 5-inch FPV freestyle drones, offering a perfect balance of power, quality, and affordability. With options for both 4S and 6S power systems, it’s a versatile choice for a huge range of builds.

Reliable RCinpower Quality

RCinpower is known for quality, and the EX2306 Plus is no exception. It features a durable unibell design, a high-strength 4mm steel shaft, and quality NMB bearings. This robust construction ensures the motor can handle the demands of regular freestyle flying and the occasional crash, delivering consistent and smooth performance flight after flight. If you’re looking for a dependable motor from a trusted brand that delivers great performance at an accessible price point, the EX2306 Plus is the perfect choice.

4S Power or 6S Smoothness

This motor is available in two popular KV ratings to perfectly match your preferred power system. Please select your desired KV from the dropdown menu:

• 2500KV: The classic high-revving option for 4S LiPo batteries, delivering aggressive and responsive performance ideal for hard freestyle.
• 1800KV: The perfect choice for a smooth, efficient, and powerful experience on 6S LiPo batteries, great for modern freestyle.

Key Features:

• Excellent Value & Performance: A perfect balance of affordability and solid performance from a trusted, premium brand.
• 4S and 6S Options: Choose 1800KV for 6S builds or 2500KV for classic 4S performance.
• Powerful 22x7mm Stator: Provides great torque and responsive handling for 5-inch propellers.
• Durable Construction: A 4mm steel shaft and quality NMB bearings ensure this motor is a dependable workhorse for everyday flying.
• Renowned RCinpower Quality: Get the reliability and smooth build quality RCinpower is known for at a great price.

Specifications

• Brand: RCinpower
• Model: EX2306 Plus
• KV Options: $1800\text{KV}$ (for 6S) or $2500\text{KV}$ (for 4S)
• Configuration: 12N14P
• Stator Dimensions: $22\text{mm}\times 7\text{mm}$
• Shaft Diameter: 4mm Steel
• Mounting Pattern: $16\text{x}16\text{mm}$ (M3)
• Weight: $34\text{g}$ (including 3cm cable)
• Cables: 20AWG

Includes

• 1x RCinpower EX2306 Plus Motor (in selected KV)
• 1x M5 Prop Nut
• 1x Screw Set
