Introducing iFlight’s very first 5″ toothpick-style drone, the TP X5 5″ HD. It is equipped with the Beast F7 45A AIO flight controller, Caddx Nebula Nano, 2005 1900KV motors, and Nazgul 5030 propellers!

Specifications

• Flight controller: Beast F7 45A AIO
• Camera: Caddx Nebula Nano
• Motor: 2005 1900KV
• Propeller: Nazgul 5030

FC // Beast F7 AIO

• MCU: BGA-STM32F745
• Gyro: MPU6000
• Blackbox: 8Mb Onboard Flash
• BEC output: 5V 2.5A
• Barometer: BMP280
• Connector: Micro-USB
• OSD: AT7456E
• FC Firmware：IFLIGHT_F745_AIO
• Mounting pattern: 25.5*25.5mm φ3mm
• Dimensions: 32.5*32.5mm
• Weight: 8.5g

ESC // 45A 2-6S

• Uarts: 5
• Current Sensor: Yes
• Input: 2-6S LIPO
• Current scale: 200
• Constant: 45A / Burst: 50A
• BLHeli: BLHeli-S
• Telemetry: no
• ESC Firmware: BlheliS G-H-30
• Mounting pattern: 25.5*25.5mm/Φ3mm
• Dimensions: 32.5*32.5mm

Includes

• 1 x Toothpick5 HD Quadcopter
• 1 x Battery tie 15*250mm
• 1 x Battery tie 15*200mm
• 2 x 2.0mm non-slip mat
• 1 x Type-c data cable
• 1 set Nazgul Paddle
• 1 x Micro USB
• 1 x Screw pack
