Happymodel has entered the game with another competitor in the 75mm brushless whoop space. The defining feature being the ability to run on both 1s and 2s batteries depending on how fast you need to go.

The only difference between the basic and standard is the included charger. The basic version comes with a small USB charger while the standard comes with a 6-way charger.

Features

• New Crazybee F4 PRO Flight controller 1-2s Lipo compatible
• Betaflight support, multi-flight mode: ACRO/AIR/ANGLE
• New 0802 Powerful and High-efficiency Brushless motor and Smooth ESC
• Betaflight OSD support, easy to get RSSI, Voltage, current from your goggles (DSM* version no RSSI output)
• SmartAudio ready, change VTX bands, channels via OSD
• Adjust the settings and the PID of the flight controller via OSD
• Frsky Non-EU version support NON-EU Frsky transmitter D8/D16 compatible
• DSM2/DSM* version support DSM2 and DSM* compatible Spektrum transmitter
• Full telemetry function ready
• Headlights ready
• Camera angle adjustable
• Real Bind and Fly version
• Buzzer Ready

Specifications

Drone

• Wheelbase: 75mm
• Size: 98mm*98mm*36mm
• Weight: 25.9g (without battery)
• Weight:40g (with Original 250mah lipo battery x2 )

Crazybee F4 V2.0 Pro Flight Controller Item Name: Crazybee F4 Pro FC

• MCU: STM32F411CEUb (72MHZ, 256K FLASH)
• Sensor: MPU-6000 (SPI connection)
• Board size: 28.5 * 28.5MM
• Power supply: 1-2S battery input (DC 3.5-8.7V)
• Built-in 5A(each) Blheli_S 4in1 ESC Dshot600 ready
• Built-in Receiver ( Different version having a different receiver)
• Built-in Betaflight OSD(SPI Control)
• Built-in Current meter Max 28A
• Current meter scale set to 1175
• Built-in 5V 1A BEC with LC filter
• Built-in voltage detection
• BLHELI_S pass-through Ready
• Heading LED Ready

Firmware

• (Frsky version) CRAZYBEEF4 PRO FR Firmware target: CrazybeeF4FR
• (Flysky version) CRAZYBEEF4 PRO FS Firmware target: CrazybeeF4FS
• (DSM2/DSMX version) CRAZYBEEF4 PRO Firmware target: CrazybeeF4DX
• (Frsky EU-LBT version) CRAZYBEEF4 PRO FS Firmware target: CrazybeeF4FS

Onboard 5A 4 In 1 ESC

• Power supply: 1-2S LiPo/LiPo HV (3.5v/8.7v)
• MCU upgraded to EFM8BB21
• Current: 5A continuous peak 6A (3 seconds)
• Support BLHeliSuite programmable
• Factory firmware: S_H_50_REV16_7
• Default protocol: DSHOT600

Onboard Frsky US Receiver Version

• SPI BUS receiver
• Frsky D8/D16 switchable
• Compatible Non-EU transmitter both D8 and D16 mode
• Channels: 8ch or 16ch
• Failsafe support
• No ground interference ( Transmitter and receiver 1 m from the ground): 300m

SE0802 16000KV Motor

• Model: SE0802
• KV: 16000KV
• Configuration: 9N12P
• Stator Diameter: 8mm
• Stator Length: 2mm
• Shaft Diameter: F1.0
• Motor Dimension (Dia.*Len) : F10.5*14.5mm
• Weight: 1.8g
• Support 1-2S Lipo

Propeller

• 40mm 4-blade Propeller ( 4 CW + 4 CCW)

5.8G VTX AIO Camera

• 5.8G 40CH 25mW VTX
• Output power: 25mw
• Frequency: 40CH
• Input voltage: 3.3V 5.5V
• Current consumption: 300mA(type)

700TVL FOV120 Camera

• Camera resolution: 700TVL
• Field of view: 120°
• Video Format: NTSC
• Antenna: RG178 antenna
• Frequency: 5.8GHz 5bands 40 channels
• With Raceband
• SmartAudio ready (Frsky EU-LBT and DSMX version not compatible)
• Size: 13.9″12.0mm ( L*W )
• Weight: 3g

Lipo Battery

• Capacity:250mAh
• Voltage:3.8v
• Continuous Discharge Rate: 30C
• Instantaneous discharge rate: 60C
• Size: 55mmx12mmx7mm
• Weight: 6.5g
• Connector: PH2.0
• Notes: Need 2pcs batteries for Series circuit

Includes

Basic Version

• 1x Mobula7 V2 75mm FPV Drone
• 4x 40mm 3-Blade Propellers ( 4 CW & 4 CCW)
• 4x 3.8v 250mah 30C/60C Lipo battery
• 1x USB Lipo/LIHV Charger
• 1x Fixing Mount for Lipo Battery
• 1x Propeller Disassemble Tool
• 1x Screwdriver
