• ARM 32-bit Cortex MCU with BLHeli_32 firmware，which is faster than BLHeli_S
• Dshot signal is supported at any rate up to Dshot120
• Adopting top quality MOSFET，low resistance，excellent impulse stability；
• Aluminum heat sink effectively slow down the temperature rise.
• Full contact soldering pad，more stable soldering.

FEATURES

• ARM 32-bit Cortex MCU, frequency up to 48 MHZ.
• BLHeli_32 firmware，which is designed for superior functionality and performance.
• Supports regular 1-2ms pulse width input, as well as Oneshot125 (125-250us), Oneshot42 (41.7-83.3us) and Multshot (5- 25us). The input signal is automatically detected by the ESC upon power up.
• Dshot signal is supported at any rate up to at least Dshot1200.
• Damped light does regenerative braking, causing very fast motor retardation, and inherently also does active freewheeling.
• Supports higher KV motor and more power load, more suitable for violent flight of racing drone .
• The silicone twisted-pair of the throttle signal cable effectively reduces the crosstalk caused by signal transmission, and makes flight more stable.
• Aluminum heat sink effectively slow down the temperature rise.

SPECIFICATION

• Con. Current：45A
• Burst Current (10S)：55A
• LiPo cells：3-6S
• Weight：10g
• Size：33x16x6mm
• Typical Applications：170-450mm Multi
